Hot-selling and scarce MMBZ15VDLT1 40 Watt Peak Power Zener Diodes SOT-23 spot stock

Product Descriptions

These  dual  monolithic  silicon  zener  diodes  are  designed  for applications requiring protection capability.They are intended for use in voltage and ESD sensitive equipment such as computers, printers, business machines, communication systems, medical equipment and other  applications.  Their  dual junction  common  cathode  design protects two separate lines using only one package.These devices are ideal for situations where board space is at a premium.

Product Features

SOT-23  Package  Allows  Either  Two  Separate  Unidirectional Configurations or a Single Bidirectional Configuration

Standard Zener Breakdown Voltage Range −15 V,27 V,39 V

Peak Power −40 W @ 1.0 ms (Bidirectional),per Figure 5 Waveform

ESD Rating of Class 3B (exceeding 16 kV)per the Human Body Model

ESD Rating of IEC61000-4-2 Level 4,30 kV Contact Discharge

Low Leakage < 100 nA

Flammability Rating:UL 94 V-O

SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements;AEC-Q101 Qualified and PPAP Capable

These are Pb-Free Devices

Product Specifications

Product Photos

For more product information, please download the PDF
