Hot sale Original CD54HC4015F3A High Speed CMOS Logic Dual 4-Stage Static Shift Register 16-CDIP
Manufacturer Product Number
CD54HC4015F3A
Description
CD54HC4015F3A High Speed CMOS Logic Dual 4-Stage Static Shift Register 16-CDIP
Package Condition
Tube
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Overview
The device is embedded in CDIP package. The number of the chip's terminations sums up to 16. It is used to pack in Rail/Tube case. The part's operating supply voltage is rated 4.5V. The device is equipped with 16 pins. It is recommended to mount by Through Hole. The electronic component belongs to the HC/UH. The total number of IC chip bits is 4. It has a total of 16 pins. It is recommended that it be used at temperatures below 125°C. It should not be lower than -55°C to operate this device. This supply voltage is employed under 6V. This supply voltage is employed higher than 2V. It runs with a quiescent current of 8μA.
Product Features
With 16 pins
Quiescent Current at 8μA
Product Applications
CD54HC4015F3A Shift Registers applications.
-
temporary data storage
-
data transfer
-
data manipulation
-
store data in digital form
-
ROM Chips
-
Flash Memory
-
Cache memory in CPU
-
Data Format Converters
-
Data Processors
-
Pseudo Random Pattern Generator
Product Description
| Type# | Description |
| ANSC PART# | ANSC- CD54HC4015F3A |
| Ihs Manufacturer | Original |
| Part Package Code | DIP |
| Package Description | DIP, DIP16,.3 |
| Pin Count | 16 |
| Samacsys Manufacturer | Original |
| Count Direction | RIGHT |
| Family | HC/UH |
| JESD-30 Code | R-GDIP-T16 |
| JESD-609 Code | e0 |
| Length | 19.56 mm |
| Load Capacitance (CL) | 50 pF |
| Logic IC Type | SERIAL IN PARALLEL OUT |
| Max Frequency@Nom-Sup | 20000000 Hz |
| Max I(ol) | 0.0052 A |
| Number of Bits | 4 |
| Number of Functions | 2 |
| Number of Terminals | 16 |
| Operating Temperature-Max | 125 °C |
| Operating Temperature-Min | -55 °C |
| Output Polarity | TRUE |
| Package Body Material | CERAMIC, GLASS-SEALED |
| Package Code | DIP |
| Package Equivalence Code | DIP16,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Packing Method | TUBE |
| Power Supply Current-Max (ICC) | 0.16 mA |
| Prop. Delay@Nom-Sup | 37 ns |
| Propagation Delay (tpd) | 270 ns |
| Qualification Status | Not Qualified |
| Schmitt Trigger | NO |
| Screening Level | 38535Q/M;38534H;883B |
| Seated Height-Max | 5.08 mm |
| Supply Voltage-Max (Vsup) | 6 V |
| Supply Voltage-Min (Vsup) | 2 V |
| Supply Voltage-Nom (Vsup) | 4.5 V |
| Surface Mount | NO |
| Technology | CMOS |
| Temperature Grade | MILITARY |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Trigger Type | POSITIVE EDGE |
| Width | 7.62 mm |
| fmax-Min | 60 MHz |
