Hot-selling and scarce DM74ALS245AWM Octal 3-STATE Bus Transceiver SOP20 spot stock

Product Descriptions

This advanced low power Schottky device contains 8 pairs of 3-STATE logic elements configured as octal bus transceivers. These circuits are designed for use in memory, microprocessor systems and in asynchronous bidirectional data buses. Two way communication between buses is controlled by the (DIR) input. Data transmits either from the A bus to the B bus or from the B bus to the A bus. Both the driver and receiver outputs can be disabled via the (G) enable input which causes outputs to enter the high impedance mode so that the buses are effectively isolated.

Product Features

■ Advanced oxide-isolated, ion-implanted Schottky TTL process

■ Non-inverting logic output

■ Glitch free bus during power up and down

■ 3-STATE outputs independently controlled on A and B buses

■ Low output impedance to drive terminated transmission lines to 133Ω

■ Switching response specified into 500Ω/50 pF

■ Specified to interface with CMOS at VOH = VCC − 2V

■ PNP inputs to reduce input loading

■ Switching specifications guaranteed over full tempera ture and VCC range

​

Product Specification

    ​

Product Photos

For more product information, please download the PDF
