Hot sale original CD4047BF Configurable & programmable logic ICs CMOS Low-Power Monostable/Astable Multivibrator
Manufacturer Product Number
CD4047BF
Description
CD4047BF Configurable & programmable logic ICs CMOS Low-Power Monostable/Astable Multivibrator
Package Condition
Tube
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| General Description The CD4047B is capable of operating in either the monostable or astable mode. It requires an external capacitor (between pins 1 and 3) and an external resistor (between pins 2 and 3) to determine the output pulse width in the monostable mode, and the output frequency in the astable mode. Features ■ Wide supply voltage range: 3.0V to 15V ■ High noise immunity: 0.45 VDD (typ.) ■ Low power TTL compatibility: Fan out of 2 driving 74L or 1 driving 74LS Special Features ■ Low power consumption: special CMOS oscillator configuration ■ Monostable (one-shot) or astable (free-running) operation ■ True and complemented buffered outputs ■ Only one external R and C required Monostable Multivibrator Features ■ Positive- or negative-edge trigger ■ Output pulse width independent of trigger pulse duration ■ Retriggerable option for pulse width expansion ■ Long pulse widths possible using small RC components by means of external counter provision ■ Fast recovery time essentially independent of pulse width ■ Pulse-width accuracy maintained at duty cycles approaching 100% Astable Multivibrator Features ■ Free-running or gatable operating modes ■ 50% duty cycle ■ Oscillator output available ■ Good astable frequency stability typical= ±2% + 0.03%/°C @ 100 kHz frequency= ±0.5% + 0.015%/°C @ 10 kHz deviation (circuits trimmed to frequency VDD = 10V ±10%) Applications • Frequency discriminators • Timing circuits • Time-delay applications • Envelope detection • Frequency multiplication • Frequency division |
Product Description
| TYPE | DESCRIPTION |
| ANSC PART# | ANSC- CD4047BF |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Multivibrators | |
| Manufacturer | Original |
| Series | 4000B |
| Packaging | Tube |
| Part Status | Active |
| Logic Type | - |
| Independent Circuits | 1 |
| Schmitt Trigger Input | No |
| Propagation Delay | 150 ns |
| Current - Output High, Low | 6.8mA, 6.8mA |
| Voltage - Supply | 3 V ~ 18 V |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Package / Case | 14-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 14-CDIP |
