Hot-selling and scarce MP8761GLE-Z High Efficiency, 8A, 18V, Synchronous, Step-Down Converter QFN16 spot stock
Manufacturer Product Number
MP8761GLE-Z
Description
MP8761GLE-Z High Efficiency, 8A, 18V, Synchronous, Step-Down Converter QFN16 spot stock
Package Condition
TaPe & Reel
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The MP8761 is a fully-integrated, highfrequency, synchronous, rectified, step-down, switch-mode converter. It offers a very compact solution to achieve a 8A output current over a wide input-supply range with excellent load and line regulation. The MP8761 operates at high efficiency over a wide output-current load range.
The MP8761 uses Constant-On-Time (COT) control mode to provide fast transient response and ease loop stabilization.
An external resistor programs the operating frequency from 200kHz to 1MHz. The frequency stays nearly constant as the input supply varies with the feed-forward compensation.
The default under voltage lockout threshold is 4.1V, but a resistor network on the enable pin can increase this threshold. The soft start pin controls the output voltage startup ramp. An open drain power good signal indicates that the output is within nominal voltage range.
It has full integrated protection features that include over-current protection, over-voltage protection and thermal shutdown.
The MP8761 is available in a 3mm×4mm QFN package, and requires a minimal number of readily-available components.
Product Features
• 2.5V to 5V Operating Input Range with External 5V Bias
• 4.5V to 18V Operating Input Range with Internal Bias
• 8A Output Current
• Low RDS(ON) Internal Power MOSFETs
• Proprietary Switching-Loss-Reduction Technique
• Adaptive COT for Ultrafast Transient Response
• 1.5 PERCENT Reference Voltage Over Junction Temperature Range (−40°C to +125°C)
• Programmable Soft-Start Time
• Pre-Bias Start-Up
• Programmable Switching Frequency from 200kHz to 1MHz
• Non-Latch OCP, OVP, and Thermal Shutdown
• Output Adjustable from 0.611V to 13V
Product Applications
• Set-Top Boxes
• XDSL Modem/DSLAM
• Small-Cell Base Stations
• Personal Video Recorders
• Flat-Panel Televisions and Monitors
• Distributed Power Systems
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-MP8761GLE-Z |
| Category | Integrated Circuits (ICs) |
| Power Management (PMIC) | |
| Voltage Regulators - DC DC Switching Regulators | |
| Mfr | - |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Not For New Designs |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 18V |
| Voltage - Output (Min/Fixed) | 0.611V |
| Voltage - Output (Max) | 13V |
| Current - Output | 8A |
| Frequency - Switching | 200kHz ~ 1MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 16-PowerVFQFN |
| Supplier Device Package | 16-QFN (3x4) |
| Base Product Number | MP8761 |
