Hot-selling and scarce 74LVT16245BDL 3.3V ABT 16-bit transceiver 3-State SSOP48 spot stock

Product Descriptions

The 74LVT16245B is a high-performance BiCMOS product designed for V CC operation at 3.3V.

This device is a 16-bit transceiver featuring non-inverting 3-State bus compatible outputs in both send and receive directions. The control function implementation minimizes external timing requirements. The device features an Output Enable (OE) input for easy cascading and a Direction (DIR) input for direction control.

Product Features

•16-bit bidirectional bus interface

•3-State buffers

•Output capability: +64mA/-32mA

•TTL input and output switching levels

•Input and output interface capability to systems at 5V supply

•Bus-hold data inputs eliminate the need for external pull-up resistors to hold unused inputs

•Live insertion/extraction permitted

•Power-up 3-State

•No bus current loading when output is tied to 5V bus

•Latch-up protection exceeds 500mA per JEDEC Std 17

•ESD protection exceeds 2000V per MIL STD 883 Method 3015 and 200V per Machine Model

Product Photos

For more product information, please download the PDF

WhenCE is HIGH (deselected),the device assumes a standby mode at which the power dissipation can be reduced down to250 µW (typical) with CMOS input levels.
